Seismic Anchor Self Tapping

Screw type anchors are preferred in floor locations so anchors can be installed after isolators or equipment is in place. Anchors shall be manufactured from hardened steel and zinc electroplated for corrosion resistance. Screw type anchors shall have an evaluation report number from the ICC-ES verifying its allowable loads. Screw type anchors shall be type SAST as manufactured by Mason Industries, Inc.
Size Length (in)
3/8 4 in
1/2 5 in
5/8 6 in
3/4 7 in
